Tunnel size: 1000mm × 1000mm
X-ray Generator: Single-View
X-ray Tube Anode Voltage: 160 kV
X-ray Tube Cooling: Sealed oil bath with forced air
Wire Resolution: 38 AWG (0.1 mm)
Penetration(steel): Typical: 36 mm
Leakage Dose-rate: ≤ 0.9 μSv/h (μGy/h)
Noise Level: ≤ 65 dB
Conveyor Speed: 0.2 m/s
Conveyor Hight: approx. 300 mm
Maximum Belt Load: 250 kg (440.92 lb)
Current Leakage: ≤ 0.25 mA
Film Safety: ISO 1600 (33 DIN)
