Dimensions: 6.0in. Hx2.5in. Wx3.3in. D
15.2cm. Hx6.4cm. Wx8.5cm. D
Weight: 5.3oz./150g
Input voltage range: 4.5 to 5.5VDC host powered;
4.5 to 5.5VDC external power supply
Operating current at nominal voltage (5.0V): 175mA (typical)
Standby current (idle) at nominal voltage (5.0V): 90mA (typical)
Color: Cash register white, Twilight black
Supported host interfaces: USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Keyboard support: Supports over 90 international keyboards
Light source: 650nm Laser Diode Class 2
Scan pattern: Single line
Scan speed: 100 scans per second
Scan angle: 35°
Minimum print contrast: 20% minimum reflective difference
Skew tolerance: ±10°
Pitch tolerance: ±65°
Roll tolerance: ±60°
