YOKOGAWA AQ6370D Telecom Optical Spectrum Analyzer (600-1700nm)

Band: Optical communications

Wavelength range(nm): Min. 600; Max. 1700

Wavelength accuracy (nm): ±0.1 (Full range); ±0.04 (1450 to 1520 nm); ±0.01 (1520 to 1580 nm); ±0.02 (1580 to 1620 nm)

Wavelength linearity (nm): ±0.01 to 0.02

Wavelength resolution setting (nm): Min. 0.02; Max. 2

Maximum number of sampling: 50001

Measurement level range (dBm): Max. +20; Min.−60 (600 to 1000 nm) or−80 (1000 to 1300 nm)or −90 (1300 to 1620 nm)

Level accuracy (dB): ±0.4

Level linearity (dB): ±0.05

Level flatness (dB): ±0.1 to ±0.2

Polarization dependence (dB): ±0.05 to ±0.08

Dynamic range (dB): 50 (±0.1 nm, RES: 0.02 nm); 78 (±1.0 nm, RES: 0.05 nm)

Applicable fiber: SMF, G

Purge feature: No

Built-in cut filter for high order diffracted light: No

Light source for optical alignment: Yes

Light source for wavelength calibration: Yes
