Yokogawa 2038 32 Portable Needle-Indicator Frequency Meter (20 ~ 100 Hz)

Measurement range:20 ~ 100 Hz

Class:Class 1.0

Scale Divisions:80 divisions (1 Hz/div)

Operating Principle:Needle-indicator frequency meter (differential system)

Operating Position:Horizontal

Rated Voltages:120/240V, 120V-Can be used between 50 and 135V

240V-Can be used between 130 and 300V.

Scale Length:Approximately 135 mm (Deflection Angle: 85°)

Consumed Power:120V Approx. 1.3VA; 240V Approx. 2VA

Operating Temperature Range:0 ~ 40°C

Operating Humidity Range:30 ~ 75% RH

Storage Temperature Range:-10 ~ 50°C

Storage Humidity Range:25 ~ 80% RH

Insulating Resistance:Min. 500V DC 100 MΩ (across electrical circuitry and casing)

Withstand Voltage:2000V AC for 1 minute (across electrical circuitry and casing)

Dimension:195 x 170 x 87 mm

Weight:1.8 kg
