Max. Scale Value:30/75 V
Approximate Internal Resistance and Consumed Power: 3.8 VA
Operating Principle:Moving iron type
Class:JIS C 1102 : 1997 Class 0.5
Operating Position:Horizontal
Scale Length:Approximately 135 mm (Deflection Angle: 85°)
Operating Frequency Range:45 ~ 65 Hz
Linemax:250V
Scale Divisions150 divisions
Operating Temperature Range:0 ~ 40°C
Operating Humidity Range:30 ~ 75% RH
Storage Temperature Range:-10 ~ 50°C
Storage Humidity Range:25 ~ 80% RH
Dimension:195 x 170 x 87 mm
Weight:1.7 kg
