Max. Scale Value:0.1/0.3/1/3 mA
Approximate Internal Rresistance and Consumed Power: 750/750/278/97.5 Ω
Operating Principle:Permanent moving coil
Class:JIS C 1102 : 1997 Class 0.5 (Equivalent to class 1.0)
Operating Position:Horizontal
Scale Length:Approximately 135 mm (Deflection Angle: 85°)
Scale Divisions:100/150
Linemax:250V (Ammerters only)
Operating Temperature Range:0 ~ 46°C
Operating Humidity Range:30 ~ 75% RH
Storage Temperature Range:-10 ~ 50°C
Storage Humidity Range:25 ~ 80% RH
Dimension:195 x 170 x 87 mm
Weight:1.7 kg
Standard Accessories:Instruction Manual
