YMC PIEZOTRONICS YMC 8602 Dynamic Strain Amplifier (DC: 0 ~ ±100mV; AC: 0 ~ ±10000mV)

Input Channels: 1

Bridge Resistance: 120 – 1000Ω

Input Range: DC: 0 ~ ±100mV; AC: 0 ~ ±10000mV

Output Range: ±10V/5mA

Noise: ≤3μV

Stability: — (not specified)

Bridge Voltage: 12VDC/50mA

Classification: DC: 100; 1000 — AC: 1; 10

Gain Accuracy: ≤±0.5%

Non-linearity: 0.1% F.S

Balance: Auto Clear Zero

Frequency Range: DC – 100kHz

Low-pass Filters (-3dB): 100kHz

Operating Environment: –10 to 50°C; Humidity: 85% R.H.

Power Supply: 220V ±10% 50Hz 0.2A

Size: 155W × 70H × 200D mm

Weight: 2.0 Kg

Input/Output Type:

Input: 4 pin LEMO Socket

Output: BNC
