YMC PIEZOTRONICS YMC 8104 Multi-Channel High Precision Charge Amplifier (±10^5pC)

Channel No.: 1–4

Input Range: ±10⁶ pC

Sensitivity Uniformization: 1.00 ~ 10.99

Gain (mV/pC): 0.01 ~ 1000 (10dB increasing)

High–pass Filters (Hz):

A: 0.1, 1, 10

V: 1, 10

D: 1, 10

Low–pass Filters (kHz): 0.1, 1.3, 10, 22.4, 30, 100

Accuracy (%): ±0.5

Noise (µV): ≤1

Output Range (V): ±10

Power Supply:

Built-in rechargeable battery;

External DC power supply: 10 ~ 33 VDC;

External AC power supply: 90-264V,40～65Hz

Operating Temperature (℃): −10 ~ +50

Weight (kg): 3.2

Size (mm): 90×144×230
