YMC PIEZOTRONICS YMC 146A01 High Sensitivity Triaxial Accelerometer (±5 g pk, 1 V/g)
ModelYMC 146A01
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Sensitivity (±10%): 1 V/g
Measuring range g pk: ±5
Resolution mg rms: 0.1
Frequency Range Hz: 0.2~1k(±10%)
Resonant Frequency kHz: 10 kHz
Temperature Range℃: –40℃ ~ +100℃
Sensing Element: Ceramic/Shear
Output Connector: 4 pin M12
Housing Material: Stainless Steel
Sealing: Epoxy Glue
Weight (g): 40g
Size (mm): 42x42x20
Mounting: Φ6(Thru-hole)/M6
