Water purifying method: Ion exchange → distillation → filtration
Sampled pure water method: Ion-exchanged water / distilled water
Distilled water production: About 1.5L / h
Amount of distilled water collected: ~ Approximately 2.5 L / min (with variable flow rate function) * 2
Ion-exchanged water sampling amount: Approximately 1.0 L / min (without variable flow rate function) * 2
Collection capacity setting range: 0.01 ~ Tank water storage L / Continuous water sampling * 3
Condenser: Hard glass
Heater: Ceramic heater 1.2kW
Pretreatment cartridge: 0.1 μm hollow fiber membrane + activated carbon (PWF-1)
Ion exchange resin cartridge: 1 CPC-S 4L type (cartridge with activated carbon)
Distilled water / ionized water final filtration: 0.1μｍ×2
leak detection: Forced shutoff of water supply solenoid valve by leak detection sensor at the time of leak
Distilled water storage tank: 30L polyethylene tank
Distilled water UV sterilization: Optional
Water sampling sink: Push-open type, load capacity: 10 kg, 5 L for beakers with hands
Multipurpose distilled water sampling port: For Φ8 hard tube connection (right side of the main body)
Standard raw water pressure range: 0.05～0.5 MPa
Standard Raw water requirement: Approx. 2.0 L/min
Standard ambient temperature range: 5～35 ℃
Function Distilled water tank water level display: 1L unit
Distilled water tank full water setting: 2，10，20，30L
Display / setting Water quality display: Conductivity / resistivity (switching)
Display / Settings Other displays: Notification: Consumables replacement / Periodic maintenance, Alarm: Water outage / Trend data recording impossible / Power failure / Distilled water quality deterioration, Abnormal: Controller / Water leakage / Heater overheating / disconnection / Tank water level gauge / Boiler water level, Water level gauge / Boiler drainage route / Cooling water / Water quality meter / Water sampling pump, / Ion exchanged water flow rate decrease / Water sampling route
Accessories: 1 water supply hose (2 m), 1 water supply hose filter, 1 connection hose assembly, 1 can stone cleaner, 1 pretreatment cartridge, 1 ion exchange resin cartridge, 1 air vent filter, 2 membrane filters , 2 filter covers, 2 magnet hooks, 1 copy of instruction manual (operation / structure), 1 warranty
External dimensions（W×D×H mm): 540×570×775mm
Power Source:
AC220V
Single phase with step-down transformer
Weight: 63kg
