Yamato LDL-N180L Fume Hood for Low Level RI (88 Pa)

External dimensions（W×D×H mm）: 1800×750×2400mm

Power Source: AC115/220V

Weight: 290kg

Exterior: Cold-rolled steel plate (chemical resistance baking finish)

Interior: Stainless steel SUS304 1mm thickness (Baffle plate: multi slit system)

Working surface materials: Stainless steel SUS304 1mm thickness (L) Max. load : 200kg

Glass window: Tempered glass 6mm Balance weight

Water faucet: Single type 1pc

Outlet: AC115/220V with dual grounding wire (dropout prevention) 1pc

Fluorescent lamp: 40W 1set

Safety feature: Exhaust delay timer, Door falling prevention stopper, Flow monitor

Option: Gas tap, LED, Safety mechanism

Standard discharge air quantity: 37 m3/min

Static pressure: 127 Pa

Datasheet
