Yamato BW101 Shaking Water Bath (12L)

Shaking type: Reciprocate shaking

Shaking width: 10 to 40 mm adjustable

Shaking speed: 20 to 160 time / min. (No step speed change)

Temperature control range: Room temperature + 5 to 80 ° C (with Immersion Type Constant Temperature Devices BF)

Material: Water bath：Stainless steel

Shaking speed control system: Feed back phase control

Shaking speed display system: Digital

Additional function: Service receptacle AC100V, 12A for BF201/401/501

Usable fluid: Water only

Drain type: Natural drain

Safety countermeasure: Electric leakage breaker, Motor overheat prevention (Automatic recovery type thermal protector)

Accessory: Shaking Rack　

Number of containers stored: Shaking Rack　Test tube（Φ15）　60pcs.　Erlenmeyer flask（50ml）　10pcs

Internal dimensions（W×D×H mm）: 230×390×150mm

External dimensions（W×D×H mm）: 295×445×285mm

Remarks(dimensions): Tank capacity approx.12L

Power Source: AC220V 6A

Single phase with step-down transformer, with BF series

Weight: 28kg
