Yamaichi Electronics HF507S-41-02 Connectors 41 PIN 0.5MM PITCH SKT W/O SHIELD, VERT
ModelHF507S-41-02
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Pitch: 0.5 mm
Gender: Female
Housing Color: Black
Actuation Type: Non ZIF
Current Rating: 300 mA
Mounting Angle: Vertical
Mounting Style: Cable
Voltage Rating: 50 V
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: SMD/SMT
Number of Positions: 41 Position
Insulation Resistance: 100 MOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 20 C
