XP Power RDF15072S05 Isolated 125W brick baseplate cooled wide 14 to 160VDC 12:1 input DC-DC converters, single output 5VDC 25A

Width: 57.9 mm (2.28 in)

Height: 12.7 mm (0.5 in)

Length: 61 mm (2.402 in)

Industry: Industrial

Dimensions: 61 mm x 57.9 mm x 12.7 mm

Output Power: 150 W

Input Voltage: 14 VDC to 160 VDC

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Input Voltage - Max: 160 V

Input Voltage - Min: 14 V

Input Voltage, Nominal: 72 V

Output Current-Channel 1: 25 A

Output Voltage-Channel 1: 5 V

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C
