XP Power FHSAA03A1FR Power Line Filters EMC FILTER, CHASSIS MOUNT, ITE, 3A
ManufacturerXP Power(View more products from this manufacturer)
ModelFHSAA03A1FR
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 24 mm
Height: 17.5 mm
Length: 44 mm
Approvals: EN60939-2, ANSI/UL1283
Compliance: EN60939-2, ANSI/UL1283
Inductance: 2 x 1.2 mH
Capacitance: 0.1 uF, 6600 pF
Filter Type: 1-Phase EMI/EMC Filter
Unit Weight: 37 g
Current Rating: 3 A
Mounting Style: Chassis Mount
Voltage Rating: 250 VAC
Leakage Current: 600 uA
Termination Style: Quick Connect
Operating Frequency: 0 Hz to 400 Hz
Maximum Operating Temperature: + 110 C
Minimum Operating Temperature: - 40 C
