Xintiho Shinrein SRN-CNC4030 Manual image measuring instrument (quick tester)

Stroke: 400*300*200 mm

Overal Dimension: 730*990*980 mm

Measurement space: 435*335 mm

weigth: 330 kg

Load capacity: 25 kg

Measurement Accuracy: 3μm

Camera: SONY Colorc 1/3 ''CCD

Camera

Optical Magnification: 0.7 ~ 4.5X

Optical zoom: 30-190X

Field View object: 14 * 2.2mm

Contour and surface illumination: Round

LED and light can be set up

X, Y error only: <= (3 + L / 200) um

Included

3D projection head

Calibration certificate
