Wurth Elektronik 750341086 Flyback MID-OLTI 90-135V

Width: 18.8 mm

Height: 13.31 mm

Length: 16.9 mm

Inductance: 850 uH

Turns Ratio: 3.808:1:1

Unit Weight: 7.196 g

Power Rating: 7.7 W

Mounting Style: Through Hole

Primary Winding: Dual Primary Winding

Secondary Winding: Single Secondary Winding

Termination Style: SMD/SMT

Operating Frequency: 100 kHz

Primary Voltage Rating: 85 V to 135 V

Secondary Current Rating: 350 mA

Secondary Voltage Rating: 22 V

Operating Temperature Range: - 40 C to + 125 C

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
