Wurth Elektronik 750315504 Forward Transformer MID-HB TPS60402 2.5 mH 40 mW

Width: 8.38 mm

Height: 9.65 mm

Length: 7.87 mm

Inductance: 2.5 mH

Turns Ratio: 0.000715278

Unit Weight: 1.419 g

Power Rating: 40 mW

Mounting Style: SMD/SMT

Primary Winding: Dual Primary Winding

Secondary Winding: Dual Secondary Winding

Termination Style: SMD/SMT

Voltage Time - Et: 50 V/us

Operating Frequency: 30 kHz to 70 kHz

Primary Voltage Rating: 3 V to 3.6 V

Secondary Current Rating: 10 mA

Secondary Voltage Rating: 4 V

Operating Temperature Range: - 40 C to + 105 C

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
