Wurth Elektronik 750311620 Flyback MID-OLON NCL30000 1.9 mH 11.3 W

Width: 25.91 mm

Height: 10.92 mm

Length: 23.11 mm

Inductance: 1.9 mH

Turns Ratio: 5.33:1:0.761

Unit Weight: 11.200 g

Power Rating: 11.3 W

Mounting Style: SMD/SMT

Primary Winding: Dual Primary Winding

Secondary Winding: Single Secondary Winding

Termination Style: SMD/SMT

Operating Frequency: 53 kHz to 120 kHz

Primary Voltage Rating: 30 V to 190 V

Secondary Current Rating: 450 mA

Secondary Voltage Rating: 25 V

Operating Temperature Range: - 40 C to + 125 C

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
