Wurth Elektronik 692121430000 USB Type A Connectors WR-COM 3.0 TypeA THT 9Pin Vertical Female

Gender: Jack (Female)

Standard: USB 3.0

Unit Weight: 2 g

Shell Plating: Nickel

Current Rating: 1.8 A

Mounting Angle: Straight

Mounting Style: Panel Mount

Voltage Rating: 30 V

Contact Plating: Gold

Insulator Color: Blue

Number of Ports: 1 Port

Contact Material: Copper Alloy

Termination Style: Through Hole

Number of Contacts: 9 Contact

Flammability Rating: UL 94 V-0

Insulation Resistance: 100 MOhms

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 20 C
