Wurth Elektronik 61900219521 Locking WR-WTB 2.54mm Male 2Pin RtAgld TopLckg

Pitch: 2.54 mm (0.1 in)

Application: Wire-to-Board

Unit Weight: 244 mg

Housing Color: Beige

Latching Type: Friction lock

Contact Gender: Pin (Male)

Current Rating: 3 A

Mounting Angle: Right Angle

Mounting Style: Through Hole

Number of Rows: 1 Row

Voltage Rating: 250 V

Contact Plating: Tin

Contact Material: Copper Alloy

Housing Material: Nylon

Termination Style: Solder Pin

Mating Post Length: 7.5 mm (0.295 in)

Flammability Rating: UL 94 V-0

Number of Positions: 2 Position

Insulation Resistance: 1 GOhms

Termination Post Length: 3.4 mm (0.134 in)

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
