Wuhan HTi160A Thermal Infrared Imager (160×120 pixels; 0.08℃~30℃)

- Resolution: 160×120 pixels
- Thermal sensitivity: 0.08℃~ 30℃
- Accuracy: ± 0.2% ± 2 digits ( full range )
- Spatial Resolution: 2.2mrad
- Focus way: Manual Focus
- Palette: Six kinds (gulf red / anti gulf red / color red / Turacin Red / White Heat / black hot )
- Working band: 8-14um
- Temperature range: 20 ℃ to +300 ℃ ( expandable to 1500 ℃)
- Measurement Accuracy: ± 2% or 2 ℃ ( take the maximum)
- Operating ambient temperature: -15 ℃ to +50 ℃
- Storage Temperature: -40℃ to +70℃
- Humidity: 95% RH ( non- condensing )
- Power Adapter: 8V-11V DC output
- Weight: < 500 g ( including battery )
- Dimension: 170×160×80mm3
