Wöhler IR TEMP 310 Infrared thermometer (- 60~ +550 ° C)

Technical Data

Temperature probes

- Mesurement: Thermocouple Probe Scan function K type

- Measurement Range: - 64 to +1400°C (-83.2 to +2552°F)

- Operating Temperature: - 0 to + 50°C (32 to + 122°F)

- Accuracy IRT 15 – 35 °C, TAmb 25 °C: ±1% of reading or 1°C (1.8°F), whichever is higher

- Accuracy IRT= -60 to 0°C; TAmb = 23°C ± 3,0°C: ±1% of reading or 1°C (1.8°F) whichever is higher

- Accuracy IRT= 0 to 550 °C; TAmb 23°C ± 3,0°C: ±1% of reading or 1°C (1.8°F) whichever is higher

- Emissivity Range

- Distance / Spot: 12 : 1

- Resolution: 0,1°C (0,1 °F) at -82,2 to 999,9 (°C/°F), otherwise 1 °C/°F

- Response Time (90%) : 1 sec

Humidity

- Relative Humidity (RH) (Tamb 23°C ±5°C) : Mesurement Range: 1 to 99%; Accuracy: ± 3% at 20~80%, otherwise ±5%

Calculated values

- Dry bulb temperature: Mesurement Range: -20 to 65 °C; Accuracy: ± 2,5 °C

- Wet bulb temperature: Mesurement Range: -20 to 65 °C; Accuracy: ± 2,5 °C

- Dew Point temperature (DPT): Mesurement Range: -50 to 50°C; Accuracy: ± 2,5°C , at 20 to 30% RH, ±2°C at 31 to 40% RH; ±1.5°C at 41~95 % RH

Technical Data

- Internal Memory: 50 memories with temperature and emissivity

- Battery Life: Min. 30 h without Laser; Mind. 7 h with Laser

- Dimensions: 53 x 124 x 171mm

- Weight: 240 g with 2 batteries (AAA)

- Backlight: Permanent

Scope of supply:

- Wöhler IR Temp 310 infrared thermometer

- 2 AAA batteries

Manual
