Max drilling capacity: 40mm
Distance from spindle nose to column: 300-1200/1400mm
Spindle horizontal travel: 900/1100mm
Spindle vertical travel: 300-1240mm
Spindle taper: MT4
Spindle travel: 210mm
Radial arm lifting speed: 1.26m/min
Radial arm lifting distance: 650mm
Drilling depth per circle: 140mm
Spindle speed: 80-1200r/min
Spindle speed series: 6
Range of spindle feed: 0.10-0.30mm/r
Spindle feed series: 3
Main motor power: 1.5kw
Lifting motor power: 0.75kw
Hydraulic clamping motor power: 0.55kw
Coolant pump power: 40w
Table size: 550x350x350mm
Net weight: 1500kgs/1700kgs
Oversall size: 1700/1900x800x2200mm
