Worktable size: 820*230mm
Workspace: 200*400*300mm
X movement: 400mm
Y movement: 200mm
Z movement: 300mm
X rapid feed: 8000mm/min
X rapid feed: 8000mm/min
Z rapid feed: 6000mm/min
Feed system: Ball screw/Linear guideway
X axis motor: Servo motor
Y axis motor: Servo motor
Z axis motor: Servo motor
Minimum movement precision: 0.07mm
Repeat accuracy: 0.01mm
Input power: 380v/3phase
Spindle speed range: 8000RPM
Packing size L x W x H: 1900*1600*2000mm
Gross weight: 1300kg
