Max.swing over bed: 500mm
Max.swing over cross slide: 325mm
Max.swing over gap: 630mm
Effective length of gap: CC: 260mm
Center Distance: 1000/1500/2000/3000
Bed Width: 330mm
Spindle hole: 65mm
Spindle nose: ISO-D6
Spindle speed(Number): (15steps)20-1800rpm
Longitudinal feeds range: 66kinds 0.072-4.038mm/rev(0.0027 0.15inch/rev)
Cross feeds range: 66kinds 0.036-2.019mm/rev(0.0013-0.075inch/rev)
Metric threads range: 66kinds 0.5-28mm
Inch threads range: 66 kinds 1-56inch
Max.travel of cross slide: 300mm
Max.size of tool shank: 20×20mm/25×25mm
Dia.of tail stock sleeve: 65mm
Taper of tail stock sleeve: MT5
Max.travel of tail stock: 120mm
Main drive motor: 7.5kw or 5.5kw
Coolant pump motor: 125W
Packing size: 2420/2920/3460/4720×1150×1800mm
