Vitrek V76 Hipot Testers (115 or 230VAC ±10%)

Test Functions: AC Hipot, DC Hipot, IR,Low Resistance, 16 Ch HV Scanner

DSP Measurement: 40,000 samples per second for output control and parameter measurement

Display: 4.3" 480 x 272 Color touch LCD user interface

Interfaces: USB 2.0, Scanner Control port (N/A on V75), RS232 and Contact Closure Digital I/O with Safety Interlock, User

Standard Accessories: Alligator test leads for hipot and continuity units (TL-209), 4-wire alligator test leads for GB units (K-2R), operator's manual CD, QT Pro V utility software, evaluation version, QT Pro test automation software and power cord

Power: 115 or 230VAC ±10% factory set, 50-60Hz, 200VA max

Dimensions: 5.25" (133mm) H x 9.5" (240mm) W x 11" (280mm) D

Weight: 12 lbs, 5.5kg net

Datasheet

Manual
