Vitrek DL250 DC electronics load (500V/42A/250W)

5 Inch LCD Touch Screen

Showing results “real-time”

Battery test function ( A.Hr, W.Hr )

Historical data logging

Oscilloscope function

X/Y plot – between I and V, V and P.

Application: IoT, LED driver, Battery, charger, etc.

Operation mode: CC; CV, CR, CW

Connections: LAN, USB.

- Input voltage 0-500; Accuracy: 0.04% + 1mV

- Input current: 0 –42A (max 60A); Accuracy: 0.05%+60µA

- 250W capacity; max 4.8Kw under 100µs

- Power supply: 12 VDC; 60VA

-Weight: 8lb (3.6Kg .)

-Operating temperature: 0-40 degrees Celsius

Datasheet
