Vishay Siliconix SIP32475DN-T1-GE4 Load Switch 1.2-5.5V; 47mohm 3uA 160us; uDFN-4
ModelSIP32475DN-T1-GE4
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Unit Weight: 28.610 mg
On Time - Max: 138 us
Mounting Style: SMD/SMT
Off Time - Max: 3 us
Output Current: 2 A
Number of Outputs: 1 Output
On Resistance - Max: 60 mOhms
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.2 V
Pd - Power Dissipation: 650 mW
Operating Supply Voltage: 1.2 V to 5.5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
