Vishay Roederstein MKP1847H61025JP4 Metallized Polypropylene Film Capacitors 10uF 250volts 5% High Humidity

ESR: 6.5 mOhms

Width: 21.5 mm (0.846 in)

Height: 38.5 mm (1.516 in)

Length: 42 mm (1.654 in)

Tolerance: 5 %

Dielectric: Polypropylene (PP)

Lead Style: Straight

Capacitance: 10 uF

Unit Weight: 52.211 g

Lead Spacing: 37.5 mm (1.476 in)

Pitch Spacing: 37.5 mm

Number of Pins: 4 Pin

Termination Style: Radial

Voltage Rating AC: 250 VAC

Voltage Rating DC: 500 VDC

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 60 C
