Vishay General Semiconductor VS-SD600N20PC Standard Recovery Rectifier 2000 Volt 600 Amp
ModelVS-SD600N20PC
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 45 mm
Height: 45 mm
Length: 255 mm
Unit Weight: 685 g
Configuration: Single
Mounting Style: Stud Mount
Max Surge Current: 13 kA
If - Forward Current: 600 A
Ir - Reverse Current: 35 mA
Vf - Forward Voltage: 1.31 V
Vr - Reverse Voltage: 2 kV
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 40 C
