Vishay Dale IHTH1125KZEB6R8M5A Power Choke 6.8uH 20%
ManufacturerVishay Dale(View more products from this manufacturer)
ModelIHTH1125KZEB6R8M5A
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Length: 10.744 mm
Diameter: 28.575 mm
Shielding: Shielded
Tolerance: 20 %
Inductance: 6.8 uH
Application: High Current
Termination: Standard
Lead Spacing: 18.288 mm
Core Material: Composite
Lead Diameter: 2.007 mm
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: Radial
Maximum DC Current: 44.5 A
Saturation Current: 44 A
Maximum DC Resistance: 1.97 mOhms
Self Resonant Frequency: 9.35 MHz
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
