VICTOR 6411 Clamp Type Grounding Resistance Tester (0.010-200Ω, 0-30.00A)

Measuring range

Resistance (Ω): 0.010-200

Current (A): 0-30.00

Resistance accuracy Ω

0.010-0.099: ±(1%+0.01)

0.10-0.99: ±(1%+0.01)

1.0-49.9: ±(1%+0.1)

50.0-99.5±(2%+0.5)

100-199±(3%+1)

Current accuracy

0~80mA: ±(2.5%+1mA)

80mA~650mA: ±(2.5%+2mA)

650mA~4A: ±(2.5%+10mA)

4A~30A: ±(2.5%＋20mA)

Maximum resolution

Ω: 0.001

mA: 0.05

Post time:6S

Data storage: 99group

Jaw size:32mm

Single measurement time:1S

Resistance measurement frequency:>1KHz

Measured current frequency:50/60Hz automatic

Resistance alarm threshold setting range:1-199Ω

Current alarm threshold setting range:1-499mA

Degree of protection:Double insulation

Source:6VDC

Body size:293*90*66mm
