VICTOR 3305 DC Power Supply Stabilization (0 ~ 30V, 0 ~ 5A)

Voltage output: 0-30V

Maximum current output: 5A

Output voltage channel: 3 channels (the voltage output of the third channel is fixed at 5V, and the current output is 1A)

Series: 60V/3A Parallel: 30V/6A

Voltage stabilization feature

Output voltage: Continuously adjustable from 0 to rated voltage

Source effect: ≤1×10ˉ4+3mV(±10% of rated source voltage)

Load effect

≤1×10ˉ4+3mV (output current≤3A)

≤3×10ˉ4+3mV (output current≥3A)

Ripple and Noise: ≤1mVrms (5Hz-1MHz)

Recovery Time: ≤100μS (50% load change, Minimum load 0.5A)

Temperature drift: ≤300ppm/°C

Current stabilization feature

Output current: Continuously adjustable from 0 to rated current

Source effect: ≤2×10-3 +3mA

Load effect: ≤2×10-3 +3mA

Ripple and Noise: ≤3mArms

Tracking feature

Source effect: ≤1×10ˉ4+5mV

Load effect: ≤300mV

Parallel feature

Source effect: ≤1×10ˉ4+3mV

Load effect: ≤1×10ˉ4+3mV (output current≤3A)

Display feature

Voltage: Two sets 3-digit voltage LED display, the display accuracy: ± (0.5% + 2 words)

Current: Two sets 3-digit current LED display, the display accuracy: ± (0.5% + 2 words)

Size: 300*250*145mm

Weight: 6900g

Power: AC220V/AC110V土10%,50Hz/60Hz
