VICTOR 3010A DC Power Supply Stabilization (0 ~ 32V, 0 ~ 10A)

Output voltage: 0~32V

Output current: 0~10A

USB charging √

LED: Dual 4-digit LED display

Operating Voltage: AC 220V+10% 50Hz

Working conditions: 0~40℃≤85%RH

Storage conditions: 0~60℃≤85%RH

Lock function: have

Weight: 2kg

Size: 221*155*103mm

Cooling method: Aluminum+ air cooling

Voltage stabilization characteristics

Load regulation rate: 0.1%+10mV

Power regulation rate:≤0.01+5mV

Voltage resolution: 4-digit display: 10mV

Display accuracy: 4-digit display≤±(0.2%+5 d)

Readback resolution: 4-digit display: 10mV

Readback accuracy: 4-digit display≤ ±(0.2%+5 d)

Steady flow characteristics

Load regulation rate: ≤0.2%+10mA

Power regulation rate: ≤0.2%+3mA

Current resolution: 4-digit display: 10mA

Display accuracy: 4-digit display≤±(0.2%+5 d)

Readback resolution: 4-digit display: 1mA

Readback accuracy: 4-digit display≤ ±(0.2%+5 d)

Ripple: 5mA

OVP: 0--32士0.2%FS

Maximum voltage: 0--32V±0.2%

OCP: 0-6A±0.2%FS

Maximum current: 6A±0.2%

Datasheet
