Width: 61 mm
Height: 12.7 mm
Length: 116.8 mm
Industry: Industrial
Approvals: CE, CSA 60950-1, cTUVus, cURus, EN60950-1, UL60950-1
Compliance: CE, CSA 60950-1, cTUVus, cURus, EN60950-1, UL60950-1
Unit Weight: 180 g
Output Power: 675 W
REACH - SVHC: Details
Input Voltage: 85 VAC to 264 VAC
Mounting Style: PCB
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Not Regulated
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Voltage-Channel 1: 258 V to 370 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 25 C
