Vicor DCM300P120M400A40 Isolated 300Vin 12V 400W

Width: 22.8 mm (0.898 in)

Height: 7.26 mm (0.286 in)

Length: 47.9 mm (1.886 in)

Industry: Industrial

Output Power: 400 W

Input Voltage: 180 V to 420 V

Mounting Style: Through Hole

Isolation Voltage: 4.242 kV

Number of Outputs: 1 Output

Input Voltage - Max: 420 V

Input Voltage - Min: 180 V

Input Voltage, Nominal: 300 V

Output Current-Channel 1: 33.4 A

Output Voltage-Channel 1: 12 V

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
