Flow: 198 l/min; 7 CFM
Vacuum Level (Partial / Total): 0.2 Pa / 15 microns
Motor Power: 0.74 kW (1 HP)
Compression Stages: 2
Power Supply: 230 V
Frequency: 50 - 60 Hz
Power Cord Length: 200 cm
Motor Speed at 50 Hz: 1400 rpm
Noise Level: 65 dB
Inlet Connection: 1/4" SAE
Oil Capacity: 0.5 l
Oil Type: mineral, viscosity: 46 mm²/s
Dimensions: 395 × 145 × 318 mm
Weight: 17.0 kg
Protection Class: IP44
Operating Temperature: 5 - 40°C
Storage Temperature: -20 - 60°C
Minimum Oil Temperature for Startup: 5°C
Shut-Off Valve: yes
Exhaust Plug Thread: M33 × 1.5 mm
Vacuum Gauge: external
Vacuum Gauge Size: 80 mm
Vacuum Gauge Accuracy: class 1.6
Vacuum Gauge Units: psi / MPa / mbar
