UNI-T UTP3303-II Linear DC power supply (3CH, 32V, 3A, 10mV, 1mA)

Voltage range CH1/2: 0-32V

Current range CH1/2: 0-3A

Voltage range CH3: 5V

Current range CH3: 3A

Power: 207W

Setting accuracy: 10mV/1mA

Ripple: ≤ 1mVrms/3mArms

Dimensions: 226 x 146 x 319 mm

Weight: 9.2 kg

Load regulation: CV<0.01%+3mV，CC≤0.2%+3mA

Output regulation resolution: CV: 10mV (typical), CC: 1mA (typical)

Tracking bias: +(0.1% of reading+30mV); CC:±(0.3% of reading+5mA/10mA

Reliability: MTBF(e): ≥2000hrs

Display mode: 4-bit voltage and current dual display

Power: Input voltage: 115V AC/230V AC; Frequency: 47Hz~63Hz

Display: 4 windows,LED

Features:

3-channel linear DC power supplies feature

High-precision four-digit voltage and current display 10mV/1mA

Low ripple/noise

Parallel/series

Output on/off control
