DC voltage: 1000V ±(0.25%+5)
AC voltage: 1000V ±(0.4%+40)
DC current (A): 10A ±(0.15%+2)
AC current (A): 10A ±(0.75%+5)
Resistance (Ω): 60MΩ ±(0.05%+2)
Admittance (nS): 60nS ±(1%＋10)
Capacitance: 60mF ±(2.5%+40)
Frequency: 10Hz ~ 10MHz ±(0.01%+5)
Temperature (°C): -40°C~1000°C±(1%+30)
Temperature (°F): -40°F~1832°F±(1.5%+50)
Duty cycle: 0.1%~99.9%
Display count: 40000
Auto/Manual range: Yes
True RMS: Yes
Bandwidth (Hz): 100kHz
4~20mA loop: 0~100%
LoZ (ACV): ≈ 3kΩ
Diode: Around 3V
Continuity buzzer: Yes
Duty cycle: 0.1%~99.9%
NCV/Data hold/MAX/MIN: Yes
Relative mode: Yes
Data storage: 9999
Display type: EBTN
Analog bar graph: 31
LCD backlight: Yes
Mis-plug alarm: Yes
Low battery indication: Yes
Auto power off: Yes
Input protection: Yes
Input impedance for DCV: Around 1GΩ
1m drop test: Yes
Safety rating: No
Power: 7.4V 2000mAh Li-ion battery
Display: 70.6mm x 35.3mm
Product color: Red and grey
Product net weight: 384g
Product size: 206mm x 95mm x 55mm
Standard accessories: Batteries, test leads, point contact temperature probe, USB interface cable, power adptor, PC software CD
Optional accessory: Bluetooth adaptor (UT-D07)
