Twintex TP30-20S DC Power Supply (30V, 20A, 600W)

Rated Output:

Voltage: 0~30V

Current: 0~20A

Power: 600W

O.V.P Range: DC 1~100% of rated output

O.C.P Range: Fixed DC 105% of maximum output

Current Stability: CV ≤0.2% +2 digits; CC ≤0.5% +2 digits

Load Stability: ≤0.5% +2 digits

Ripple and Noise (5Hz~1MHz): ≤1% rms full scale

Display:

Voltmeter: 4-digit LED display

Ammeter: 4-digit LED display

Voltage Resolution: 0.000-9.999V; 00.00-99.99V; 000.0-999.9V

Current Resolution: 0.000-9.999A; 00.00-99.99A; 000.0-999.9A

Accuracy: ±(1% FS +1 digit)

Optional Functions:

Meter Display: 4 1/2 digit LED display (Maximum display 19999)

Output Terminals: On the front panel; or on the rear panel; or on both front and rear panels

Output On/Off: Front panel switch; Terminal block or rear panel wires for remote control

General Specifications:

Protection: Over-voltage, over-current, over-temperature, and overload protection

Operating Environment: 0℃~40℃, ≤80% RH

Storage Environment: -10℃~70℃, ≤80% RH

Input Module: Power socket or terminal block
