Twintex TP1305EC Power Supply (0~30V/0~5A)

Output voltage: 0-30V

Output current: 0-5A

Dimension (WxHxD): 130x160x255mm

Weight: 5.5kg

Constant voltage operation

- Line regulation: ≤0.01%+3mV

- Load regulation: ≤0.02%+5mV

- Ripple & Noise (5Hz-1MHZ): ≤3mVrms

Constant current operation

- Line regulation: ≤0.2%+3mA

- Load regulation: ≤0.2%+5mA

Fixed output

- Load regulation: ≤25mV@110/220VAC rated input

- Ripple & noise (5Hz-1MHz): ≤3mVrms

Display

- Resolution: 100mV/10mA

- Accuracy: ±(1% reading+2 digits)

Power source: AC110V/220V±10%, 50/60Hz

Included Accessories: Power cord x1, Operation manual x1
