True Phantom Solutions BT-A01 Adult Breast (Complex) For X-Ray CT, US, MRI

Size: 10 x 9 x 10 Inches

Weight: 11 Lbs (approx.)

Organs with Speckles (liver, kidneys, etc.)

Sound velocity / Density / Hardness / T2 / Speckles / Attenuation at 2.25 MHz

1435 ± 10 m/s / 0.99 g/cm³ / 20 Shore OO / 70 ms / VARIABLE / 1.0 ± 0.2 dB/cm

Organs without Speckles (stomach, intestines, etc.)

Sound velocity / Density / Hardness / T2 / Speckles / Attenuation at 2.25 MHz

1400 ± 10 m/s / 0.99 g/cm³ / 20 Shore OO / 70 ms / NO / 1.0 ± 0.2 dB/cm

Body Tissue

Sound velocity / Density / Hardness / T2 / Speckles / Attenuation at 2.25 MHz

1410 ± 10 m/s / 1.00 g/cm³ / 35 Shore OO / 55 ms / NO/LOW / 1.5 ± 0.2 dB/cm

Tumor Feature

Sound velocity / Density / Hardness / T2 / Speckles / Attenuation at 2.25 MHz

1400 ± 10 m/s / 1.01 g/cm³ / 30 Shore OO / 65 ms / YES / 1.2 ± 0.2 dB/cm

Cortical Bone

Sound velocity / Density / Hardness / T2 / Speckles / Attenuation at 2.25 MHz

3000 ± 30 m/s / 2.31 g/cm³ / N/A / N/A / N/A / 6.4 ± 0.3 dB/cm

Trabecular Bone

Sound velocity / Density / Hardness / T2 / Speckles / Attenuation at 2.25 MHz

2800 ± 50 m/s / 2.03 g/cm³ / N/A / N/A / N/A / 21 ± 2 dB/cm
