Triad Magnetics CST25-0200 Current Transformers PCB Curr Sense Xfmr 1:200,50-500KHz
ManufacturerTriad Magnetics(View more products from this manufacturer)
ModelCST25-0200
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 15 mm
Height: 11.8 mm
Length: 17 mm
Inductance: 76 mH
Turns Ratio: 1:200
Unit Weight: 46.050 g
Current Rating: 25 A
Mounting Style: Through Hole
Output Current: 125 mA
Frequency Range: 50 kHz to 500 kHz
Termination Style: Solder Pin
Voltage Time - Et: 700 V
Secondary Resistance: 4.5 Ohms
Operating Temperature Range: + 40 C to + 100 C
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: + 40 C
