Trenz Electronic TE0865-02-FBE23MA System-On-Modules - SOM MPSoC Module with Zynq UltraScale+ ZU19EG-1E, 4GB DDR4 ECC (PS), 4GB DDR4 (PL)
ModelTE0865-02-FBE23MA
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Flash: 256 MB
Dimensions: 10 cm x 7.5 cm
Memory Size: 4 GB
Memory Type: DDR4
Installed RAM: 4 GB
Interface Type: eMMC, Ethernet, GPIO, I2C, JTAG, LVDS, QSPI, UART, USB
Processor Type: XCZU19EG-1FFVC1760E
Processor Brand: Xilinx
Processor Series: Zynq UltraScale+
Maximum RAM Capacity: 4 GB
On-Board Storage Size: 8 GB
On-Board Storage Type: eMMC
Operating Supply Voltage: 12 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: 0 C
