TRACO Power TMV 2-1209SHI Isolated 10.8-13.2Vin 9Vout 222mA 2W SIP-7 ISO

Width: 7.5 mm (0.295 in)

Height: 10.2 mm (0.402 in)

Length: 19.5 mm (0.768 in)

Industry: Industrial

Unit Weight: 2.400 g

Output Power: 2 W

Input Voltage: 10.8 V to 13.2 V

Mounting Style: Through Hole

Isolation Voltage: 5.2 kV

Number of Outputs: 1 Output

Input Voltage - Max: 13.2 V

Input Voltage - Min: 10.8 V

Input Voltage, Nominal: 12 V

Output Current-Channel 1: 222 mA

Output Voltage-Channel 1: 9 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
