TRACO Power TIM 6-4823 Isolated 6W 36-75Vin +/-15V 200mA DIP-24 Medical

Width: 20.3 mm (0.799 in)

Height: 10.6 mm (0.417 in)

Length: 31.8 mm (1.252 in)

Industry: Medical

Dimensions: 31.8 mm x 20.3 mm x 10.6 mm

Application: IGBT Drivers

Unit Weight: 13.500 g

Output Power: 6 W

Input Voltage: 36 VDC to 75 VDC

Mounting Style: Through Hole

Isolation Voltage: 5 kV

Number of Outputs: 2 Output

Input Voltage - Max: 75 V

Input Voltage - Min: 36 V

Input Voltage, Nominal: 48 V

Output Current-Channel 1: 200 mA

Output Current-Channel 2: 200 mA

Output Voltage-Channel 1: 15 V

Output Voltage-Channel 2: - 15 V

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
