TRACO Power THN 20-2425WIR Isolated 9-36Vin +/-24V 417mA 20W 1x1 Iso Railway

Width: 25.4 mm (1 in)

Height: 9.9 mm (0.39 in)

Length: 25.4 mm (1 in)

Industry: Industrial

Efficiency: 91 %

Unit Weight: 16 g

Output Power: 20 W

Input Voltage: 9 V to 36 V

Cooling Method: Natural convection

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 2 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 417 mA

Output Current-Channel 2: 417 mA

Output Voltage-Channel 1: 24 V

Output Voltage-Channel 2: - 24 V

Maximum Operating Temperature: + 65 C

Minimum Operating Temperature: - 40 C
