TRACO Power TDN 5-0919WISM Isolated 4.5-13.2Vin 9Vout 555mA 5W Iso Reg SMT
ManufacturerTRACO Power(View more products from this manufacturer)
ModelTDN 5-0919WISM
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 9.1 mm
Height: 10.2 mm
Length: 13.2 mm
Industry: Industrial
Unit Weight: 2.700 g
Output Power: 5 W
Input Voltage: 4.5 V to 13.2 V
Mounting Style: SMD/SMT
Isolation Voltage: 1.6 kV
Number of Outputs: 1 Output
Moisture Sensitive: Yes
Input Voltage - Max: 13.2 V
Input Voltage - Min: 4.5 V
Input Voltage, Nominal: 9 V
Output Current-Channel 1: 555 mA
Output Voltage-Channel 1: 9 V
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 40 C
