TPI 575C1 Vane and Hotwire Velocity Meter (80 ~ 4900 ft/min)

Air Velocity: 80 to 4900 ft/min

0.4 to 25 m/s 40 to 3900 ft/min

0.2 to 20 m/s

Units of Measure: m/s, km/s, ft/min, mile/hr, knots/hr

Air Velocity Accuracy: ±(2% of rdg + 3 digits) vane; >±(5% of rdg + 3 digits) hot wire

Temperature: -5°F to 175°F; -20°C to 80°C

Temperature Accuracy: ±(1% of rdg + 1°F + 3 digits)

Units of Measure: °C / °F

CFM Calculation: Manual using formula

RS-232 Output: Yes

Min/Max Record: Yes

Operating Temperature (Base Unit): 32°F to 122°F

Operating Humidity (Base Unit): <95% non-condensing

Battery Type: 9V

Battery Life: 30 hours typical

Dimension W x L x H: 2.9” x 5.7” x 1.1”

Weight: 0.3lb
